4.3″ Embedded TFT Full Control Platform, 480×272, with Resistive Touch Panel
$43.59CONTACT FOR VOLUME PRICING
19 in stock
- Diagonal Dimension: 4.3 Inch
- Resolution: 480 x 272 pixels
- Interface: RGB 24BITS
- Luminance: 260 cd/m2
- Viewing Direction: 12 o’clock
- Touch Panel: Resistive
Pricing table
| Quantity | Unit Price |
|---|---|
| 25-49 | $39.26 |
| 50- | $34.93 |
Contact us for larger volume orders and any other enquiries.
Description
ACN series provide a full control platform of TFT, it can be used the same as the monochrome LCDs.
- 3V input
- 8-line parallel MCU interface
- 8080 or 6800 interface timing
- Backlight brightness can be adjusted by outside PWM signal
- 24 bits RGB
Full Control Platform with Resistive Touch Panel 480×272 4.3″ Embedded TFT
The highest quality product at the lowest price. Ships from the USA.
- 4.3″ TFT, with full control platform, 480 x (RGB) x 272
- Color TFT / Normal Brightness Module
- Transmissive / Normal White / Resistive Touch Panel (RTP)
- 12 o’clock Viewing Direction
- Operating Temp: -20°C to 70°C
- Storage Temp: -30°C to 80°C
- ROHS Compliant
Download Product References Below
Product Datasheet: ACN480272A01-4.3N12NSM-R
Product Video Tutorials
| Model / Series Name | ACN480272A01-4.3N12NSM-R |
| Diagonal Dimension (inch) | 4.3 |
| Dots WxH | 480 x 272 |
| Module Size WxHxT max (mm) | 105.5 x 67.2 x 7.55 |
| Display Mode | Color TFT / Transmissive / Normal White |
| IC | SSD1963 |
| Interface Type | 8-line parallel MCU |
| Logic Power Supply Voltage | 3.3 V |
| Backlight | White LED |
| Luminance | 260 cd/m2 |
| Touch Panel | Resistive |
These are just few of our famous TFT modules; we still have a lot of TFT products to offer.
If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.
Additional information
| Weight | 0.63 lbs |
|---|---|
| Dimensions | 67.2 × 105.5 × 7.55 mm |
| backlightcolor | |
| diagonal-size | |
| displaytype | |
| polarizertype | |
| resolution | |
| touchpanel | |
| viewingdirection |
