AGN800480A00-7.0N12NSM-R (7″ Full-Graphic Embedded Display with Resistive TP)
$76.86CONTACT FOR VOLUME PRICING
12 in stock
- Diagonal Dimension: 7 Inch
- Resolution: 800 x 480 pixels
- Interface: UART
- Luminance: 320 cd/m2
- Viewing Direction: 12 o’clock
- Touch Panel: Resistive
Pricing table
Quantity | Unit Price |
---|---|
25-49 | $71 |
50- | $65.14 |
Contact us for larger volume orders and any other enquiries.
SKU: AGN800480A00-7.0N12NSM-R
Categories: TFT Displays Modules, Embedded LCD Display Modules, GUS System
Description
AGN series are designed for fast and reliable interactive interface for full-graphic display with touch panels. They are easy to develop, flexible, UI user friendly, and reliable. They save a lot of work on single-chip coding volume.
- Low user resource setting
- Simple UI modification
- Simple UI update
- Comprehensive peripheral features
AGN800480A00-7.0N12NSM-R
The highest quality product at the lowest price. Ships from the USA.
- 7.0″ TFT, with full control platform, 800 x (RGB) x 480
- Color TFT / Medium Brightness Module
- Transmissive / Normal White / Resistive Touch Panel (RTP)
- 12 o’clock Viewing Direction
- Operating Temp: -20°C to 70°C
- Storage Temp: -30°C to 80°C
- ROHS Compliant
Download Product References Below
Product Datasheet: AGN800480A00-7.0N12NSM-R
Product Video Tutorials
Model / Series Name | AGN800480A00-7.0N12NSM-R |
Diagonal Dimension (inch) | 7.0 |
Dots WxH | 800 x 480 |
Module Size WxHxT max (mm) | 190.4 x 105.2 x 15.0 |
Display Mode | Color TFT / Transmissive / Normal White |
Interface Type | UART |
Logic Power Supply Voltage | 3.3 V |
Backlight | White LED |
Luminance | 320 cd/m2 |
Touch Panel | Resistive |
These are just few of our famous TFT modules; we still have a lot of TFT products to offer.
If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.
Additional information
Weight | 2.25 lbs |
---|---|
Dimensions | 105.2 × 190.4 × 15 mm |
backlightcolor | |
diagonal-size | |
displaytype | |
polarizertype | |
resolution | |
touchpanel | |
viewingdirection |
Reviews (0)
Be the first to review “AGN800480A00-7.0N12NSM-R (7″ Full-Graphic Embedded Display with Resistive TP)” Cancel reply
Shipping & Delivery
Related products
2.4” TN TFT display with UART interface, 240×320, 460nits
$18.58
- Diagonal Dimension: 2.4 Inch
- Resolution: 240 x 320 pixels
- Luminance: 460cd/m2
- Viewing Direction: 6 O'clock
- Touch Panel: None
- Interface: UART
4.3″ Embedded TFT Full Control Platform, 480×272, with Resistive Touch Panel
$43.59
- Diagonal Dimension: 4.3 Inch
- Resolution: 480 x 272 pixels
- Interface: RGB 24BITS
- Luminance: 260 cd/m2
- Viewing Direction: 12 o'clock
- Touch Panel: Resistive
AGN320240A01-3.5N12NSH-R (3.5″ Full-Graphic Embedded Display with Resistive TP)
$51.99
- Diagonal Dimension: 3.5 Inch
- Resolution: 320 x 240 pixels
- Interface: UART
- Luminance: 600 cd/m2
- Viewing Direction: 12 o'clock
- Touch Panel: Resistive
AGN480272A00-4.3N12NSM-R (4.3″ Full-Graphic Embedded Display with Resistive TP)
$54.79
- Diagonal Dimension: 4.3 Inch
- Resolution: 480 x 272 pixels
- Interface: UART
- Luminance: 260 cd/m2
- Viewing Direction: 12 o'clock
- Touch Panel: Resistive
2.4” TN TFT display with UART interface, 240×320, 370nits, with Resistive Touch Panel
Medium Brightness TFT Panels, TFT with Touch Panels, Embedded LCD Display Modules, Color TFT, TFT Displays Modules
$21.34
- Diagonal Dimension: 2.4 Inch
- Resolution: 240 x 320 pixels
- Luminance: 370cd/m2
- Viewing Direction: 6 O'clock
- Touch Panel: Resistive
- Interface: UART
3.5″ Embedded TFT Full Control Platform, 320×240, with Resistive Touch Panel
$42.68
- Diagonal Dimension: 3.5 Inch
- Resolution: 320 x 240 pixels
- Interface: MCU 18BITS
- Luminance: 600 cd/m2
- Viewing Direction: 12 o'clock
- Touch Panel: Resistive
2.0” IPS TFT display with UART interface, 240×320, 480nits
$19.29
- Diagonal Dimension: 2.0 Inch
- Resolution: 240 x 320 pixels
- Luminance: 480cd/m2
- Viewing Direction: ALL
- Touch Panel: None
- Interface: UART
1.77” IPS TFT display with UART interface, 240×320, 400nits
