3.5” Capacitive Touch Panel CTP035
$16.00 $12.80CONTACT FOR VOLUME PRICING
222 in stock
- Diagonal Dimension: 3.5 Inch
- Resolution: 320 x 240pixels
- Interface: I2C
- Touch Panel: Capacitive
SKU: CTP035
Categories: Capacitive Touch Panels Displays, Touch Panels
Description
(Final Sale)
A 3.5″ Capacitive Touch Panel for 3.5” TFT.
The highest quality product at the lowest price. Ships from the USA.
- 3.5″ Capacitive Touch Panel for TFT
- Glass (Lens) + Glass (Sensor)
- 5 Point Touch
- 320 x 240 Resolution
- Operating Temp: -20°C to 70°C
- Storage Temp: -20°C to 80°C
- ROHS Compliant
Model / Series Name | CTP035 |
Diagonal Dimension (inch) | 3.5 |
Dots WxH | 320 x 240 |
Cover Lens Size WxHxT (mm) | 76.9 x 63.9 x 1.1 |
Sensor Size WxHxT (mm) | 76.5 x 63.3 x 0.55 |
IC | MXT224E |
Interface Type | I2C |
Power Voltage | 3.3V |
Operating Temp | -20°C to 70°C |
Storage Temp | -20°C to 80°C |
Structure | Glass (Lens) + Glass (Sensor) |
These are just few of our famous Touch Panels; we still have a lot of Touch Panel products to offer.
If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.
Additional information
Weight | 0.049 lbs |
---|---|
Dimensions | 77 × 90 × 2 mm |
Diagonal Size (Inch) | 3.5 |
resolution | |
Touch Panel | Capacitive Touch Panel |
