AMCT-1 (Demo Board for Character LCD Modules)
AMCT-1 (Demo Board for Character LCD Modules)
HomeDemo Board & Display Accessories AMCT-1 (Demo Board for Character LCD Modules)
Previous product
AMC4004CR-B-Y6WFDY (40x4 Character LCD Module)
AMC4004CR-B-Y6WFDY (40x4 Character LCD Module) $20.50
Back to products
Next product
AMG24064AR-M-Y6WFDY-NV (5.2" 240x64 Graphic LCD Module)
AMG24064AR-M-Y6WFDY-NV (5.2" 240x64 Graphic LCD Module) $40.63

AMCT-1 (Demo Board for Character LCD Modules)

$50.00CONTACT FOR VOLUME PRICING

  • CHARACTER LCD MODULE EVALUATION & DEVELOPMENT BOARD
  • For ALL our Character LCD Modules

8 in stock

Compare
Add to wishlist
SKU: AMCT-1 Category: Demo Board & Display Accessories
Share
Facebook Email linkedin
  • Description
  • Additional information
  • Reviews (0)
  • Shipping & Delivery

The AMCT-1 is the newly developed FIRST CHARACTER LCD MODULE EVALUATION & DEVELOPMENT BOARD. This can be used to test almost all of our Character LCD modules.

This evaluation / tester kit has the following features:

  • It uses Atmel AT89C4051 processor to control the LCM and communicates to the PC by RS232
  • It interfaces to the most modules that use the industry-standard HD44780 controller (or equivalent), running in 8-bit or 4-bit model (software select).
  • It allows engineers to light up a character LCD module within few minutes which is very beneficial in showing newly designed ideas.
  • It can evaluate if an LCD module is still in a good condition or not. It can also assess the LCD’s contrast, viewing angle, backlight brightness and other settings. It is a very efficient way to find out if either software or hardware is having problems.
  • IT can also test modules faster by using special clips together, supplied by AV display. It will be very useful for quality with IQC, production with PQC and 100% screening before production.

Click here to see the AMCT-1 Operations Manual


Please visit Orient Display to see the full range of Character LCD Modules, Graphic LCD Modules, LCD Glass Panels, and Full Colored TFT Modules that we can offer.



Please send your inquiries to info@orientdisplay.com
Weight 2.61 lbs
Dimensions 65 × 85 × 18 mm
displaytype

Demo Board
