2 inch mcu interface display
HomeTFT DisplaysColor TFT 2.0″ TN display, 240×320, 230 Nits, MCU Interface
Previous product
1.77" TN display, 128x160, 320 Nits, SPI Interface $5.58
Back to products
Next product
3.5" TN display, 320x480, 360 Nits, SPI+RGB Interface $16.33

2.0″ TN display, 240×320, 230 Nits, MCU Interface

$9.88CONTACT FOR VOLUME PRICING

93 in stock

  • Normal Brightness / TN display
  • Diagonal Dimension: 2.0 Inch
  • Resolution: 240 x 320 pixels
  • Interface: MCU
  • Luminance: 230 cd/m2
  • Viewing Direction: 6 o’clock
  • Touch Panel: None

Pricing table

QuantityUnit Price
25-49$8.69
50-$7.5

Contact us for larger volume orders and any other enquiries.

Compare
Add to wishlist
SKU: AFK240320A0-2.0N6NTN Categories: Color TFT, Special Size TFT Panels
Share
Facebook Email linkedin

Description



A simple 2.0″ Normal Brightness / TN Module, Transmissive / 6 o’clock Viewing Direction / Normal White with 240 x 320 dots.

2 Inch MCU Interface Display – details

The highest quality product at the lowest price. Ships from the USA.
  • 2.0″ TN, 240 x 320
  • Normal Brightness / TN
  • Transmissive / Normal White
  • 6 o’clock Viewing Direction
  • Operating Temp: -20°C to 70°C
  • Storage Temp: -30°C to 80°C
  • ROHS Compliant


Download Product References Below

Product Datasheet: AFK240320A0-2.0N6NTN
Controller Datasheet: ILI9341V
Optional Accessory: TBD



Model / Series Name AFK240320A0-2.0N6NTN
Diagonal Dimension (Inches) 2.0
Dots WxH 240 x 320
Module Size WxHxD max (mm) 37.88 x 51.5 x 2.5
Display Mode TN / Normal White / Transmissive
IC ILI9341V
Interface Type MCU Interface
Logic Power Supply Voltage 3.3
Backlight LED, WHITE, If=15mA
Luminance 230 cd/m2
Touch Panel None

These are just few of our famous TFT modules; we still have a lot of TFT products to offer.

If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.

Additional information

Weight 0.0189598 lbs
Dimensions 38 × 90 × 3 mm
backlightcolor

White

diagonal-size

2.0

displaytype

TFT – TN

polarizertype

Transmissive

resolution

240×320

touchpanel

None

viewingdirection

6 o'clock
