2.4” TN TFT display with UART interface, 240×320, 460nits
$18.58CONTACT FOR VOLUME PRICING
9 in stock
- Diagonal Dimension: 2.4 Inch
- Resolution: 240 x 320 pixels
- Luminance: 460cd/m2
- Viewing Direction: 6 O’clock
- Touch Panel: None
- Interface: UART
SKU: AGU240320A00-2.4N6NSM
Categories: Medium Brightness TFT Panels, TFT Displays Modules, U-series UART Interface, Embedded LCD Display Modules, Color TFT
Description
2.4″ TN TFT Display with UART interface, 240×320, Full Color / Normal Brightness TFT Module, Transmissive.
2.4 Inch TN TFT Display with UART Interface, 240×320 resolution
The highest quality product at the lowest price. Ships from the USA.
- 2.4″ TN TFT, 240 x 320 with UART interface
- Full Color / Medium Brightness TFT Module
- 6 O’clock Viewing Direction
- Transmissive
- Operating Temp: -20°C to 70°C
- Storage Temp: -30°C to 80°C
- ROHS Compliant
Download Product References Below
Drawing: AGU240320A00-2.4N6NSM
Controller Datasheet: ILI9341V
TFT Datasheet: AFY240320B0-2.4N6NTM-SPI Coming soon
Model / Series Name | AGU240320A00-2.4N6NSM |
Diagonal Dimension (inch) | 2.4 |
Dots WxH | 240 x 320 |
Module Size WxHxD max (mm) | 50.00 * 69.20 * 7.76mm (PCB) |
Display Mode | TN TFT / Transmissive / Normal White |
IC | ILI9341V |
Interface Type | UART interface |
Logic Power Supply Voltage | 3.3V |
Backlight | White LED |
Luminance | 460 cd/m2 |
Touch Panel | None |
These are just few of our famous TFT modules; we still have a lot of TFT products to offer.
If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.
