A simple 1.3″ Passive Matrix OLED, 4-line SPI and Arduino Compatible, Monochrome with White display color / All viewing direction / with 128 x 64 dots.
The highest quality product at the lowest price. Ships from the USA.
- 1.3″ OLED, 128 x 64
- All Viewing Direction
- Operating Temp: -40°C to 70°C
- Storage Temp: -40°C to 85°C
- ROHS Compliant
Â
Download Product References Below
Product Datasheet: AOM12864A0-1.3WW-ANO
Optional Accessory:Â TBD
| Model / Series Name | |
| Diagonal Dimension (Inches) | 1.3 |
| Dots WxH | 128 x 64 |
| Module Size WxHxD max (mm) | 35.4 x 33.5 x 5.0 |
| Display Mode | OLED |
| IC | SSD1306/SH1106 |
| Interface Type | 4-wire SPI / Arduino Compatible |
| Logic Power Supply Voltage | 3.3V |
| Backlight | / |
| Luminance | 60 cd/m2 |
| Touch Panel | None |
These are just few of our famous OLED modules; we still have a lot of OLED products to offer.
If none of these part numbers meet your requirements in terms of brightness, interface, or connection method, please email us at info@orientdisplay.com.
