1. Display Module Body

• IPS LCD: Wide viewing angles, suitable for outdoor multi-user and multi-angle viewing .
• LTPS LCD: An option if feasible and budget permits; offers a high aperture ratio to lower power consumption.
• High-Brightness Backlight: Generally 1000–1500 nits is recommended; consider 1500–2500 nits for intense direct sunlight environments .
• Wide-Temperature Liquid Crystal Materials: Recommended operating temperature of at least -30°C to +85°C to avoid slow response times at low temperatures and blackouts at high temperatures .
• High Contrast / High Color Gamut: Under outdoor sunlight, readability is much more critical than mere brightness .
• Anti-UV Aging Design: Outdoor UV stability must be considered for the polarizer, OCA, and cover glass printing ink .
• Wide Viewing Angle & Polarized Sunglasses Compatibility: When using IPS, verify whether the polarizer supports a Quarter-Wave Plate (1/4 wave plate). Otherwise, the screen will turn black at certain angles when users wear polarized sunglasses .In this case, sunglasses friendly film should be used.
• Heating Module (Heater): In extremely cold regions (e.g., -30°C), liquid crystals slow down or stop working entirely . An ITO heating glass or low-power heating wire must be designed into the rear side to preheat the screen before boot-up.

2. Optical Bonding & Surface Treatment

• OCA / OCR Full Bonding: Eliminates the air layer to reduce reflections, improving sunlight readability while enhancing structural strength .
• AG (Anti-Glare) Treatment: Reduces reflections from sunlight and vehicle headlights .
• AR (Anti-Reflection) Coating: Lowers surface reflectivity to increase contrast.
• AF (Anti-Fingerprint) Coating: Highly recommended for touchscreens to minimize oil and water stains. Outdoor surfaces accumulate dust and fingerprint oils easily. The surface treatment is typically a 3-in-1 AG + AR + AF combination .
• AR/AG Film: Used if the surface hardness requirement allows for below 3H.
• IR (Infrared) Reflective Film / Heat Insulation Film: Reduces solar infrared heat entering the LCD, mitigating the risk of high-temperature blackouts .
• UV Cut Film: Protects the liquid crystals, polarizer, and OCA bonding materials .

3. Cover Glass & Structural Strength

• Vandal-Resistant & Thick Cover Glass: Outdoor equipment is vulnerable to vandalism . The cover must use high-strength tempered glass (such as Corning Gorilla Glass or Asahi Glass/AGC) with a typical thickness of 4mm – 6mm to meet IK07–IK10 impact protection ratings .
• Edge Silk-Screen Shading: Prevents backlight bleeding and protects bonding materials from light exposure.
• Anti-Shatter Film / Safety Film: Worth considering for public spaces to prevent glass shards from scattering if broken.
• Waterproof Structure: The target is usually IP65 / IP66 . Focus areas include the glass-to-housing interfaces, connectors, and drainage paths .

4. Backlight & Thermal Management

• Aluminum Alloy Backplate Heat Dissipation: High-brightness LEDs generate massive heat and require an efficient thermal conduction path .
• Thermal Pads / Thermal Interface Materials (TIM) / Graphene: Connects the LED PCB, aluminum backplate, and the primary enclosure .
• Local Dimming (Mini-LED) or Brightness Throttling Strategy: Automatically dims the screen at high temperatures to protect the LEDs and LCD from thermal damage .
• High-Efficiency Backlight Driver: To reduce heat generation, the conversion efficiency of the backlight constant-current driver must exceed 90% .
• Temperature Sensors: Recommended placement near the LED light strips, LCD backplate, and main driver board .
• Direct Sunlight Thermal Design: Consider not only the ambient temperature but also the internal temperature rise caused by solar radiation .

5. Touch Design

• Outdoor Waterproof Touch (Wet Touch): Raindrops will settle on the screen surface . The touch IC (e.g., Microchip, Cypress, EETI, etc.) must support thick cover glass + operation with water + gloved operation.
• Thick Cover Glass Touch Tuning: If the glass layer is thick, verify that the IC driver capability is strong enough.
• Fully Sealed Design (IP Rating): Waterproof design between the front touch module and the housing structure requires high-elasticity waterproof foam (like PORON or waterproof resin) . The front surface generally needs to achieve IP65 or IP66 .
• EMI/EMC Protection: The interior of a charging pile contains high voltage and large currents, producing intense high-frequency switching noise . Display signal lines (LVDS/eDP) and driver boards must feature robust electromagnetic shielding to prevent screen flickering or touch failure .
• Grounding & Shielding: Ensure proper grounding for the touch FPC, cover glass ITO, and metal frame .

6. Environmental Reliability

• High and Low-Temperature Operation / Storage
• Thermal Shock
• High Temperature & High Humidity
• UV Aging
• Salt Spray Testing: Required if deployed near coastal areas or long-term outdoor exposure .
• Condensation Protection
• Resistance to Rain, Dust, and Cleaning Agents
• Risk assessment for polarizer yellowing, OCA yellowing, and bubbling under prolonged sun exposure .

7. Electrical & Interfaces

• Power margin headroom for the high-brightness backlight driver
• LED constant-current driver protection
• Over-temperature protection
• ESD (Electrostatic Discharge) protection
• EMI/EMC design
• Interface Selection: LVDS, MIPI, eDP, or HDMI, depending on screen size and the main controller platform.
• Long-Cable Transmission Stability: Pay close attention to signal integrity if the internal wiring harnesses are long .

8. Readability & System Strategies

• Ambient Light Sensor (ALS): For automatic brightness adjustment .
• Nighttime Low-Brightness Mode: Avoids blinding users and reduces power consumption .
• Smart Dimming (Auto-Dimming): Built-in photosensitive sensor . Runs at ultra-high brightness during the day to combat glare and drops to low brightness (e.g., 100 nits) at night for anti-glare and energy saving .
• Anti-Burn-In / Anti-Image Sticking Strategy: Although LCDs do not behave like OLEDs, displaying static UI elements for a long time can still cause image sticking .
• High-Contrast UI Design: Using overly thin or light-colored fonts is not recommended for outdoor screens .

9. Recommended Key Combination

For an outdoor high-brightness display on a charging pile, the following configuration is highly recommended:

IPS LCD + 1000–2000 nits High-Brightness Backlight + Full OCA/OCR Bonding + AG/AR/AF Cover Glass + IR/UV Cut Film + Aluminum Alloy Heat Dissipation Backplate + PCAP Outdoor Touch + Over IP65/IK08 Structural Design + ALS Auto-Dimming + High-Temperature Throttling Protection.



If you have any questions, please contact our engineering.

As display technology continues to evolve, consumers are increasingly seeing terms like a-Si, IGZO, LTPS, and LTPO in product specifications. While these names are often associated with LCD or OLED displays, they do not describe the display panel itself. Instead, they refer to the thin-film transistor (TFT) backplane technology that controls every individual pixel.

The TFT backplane plays a critical role in determining display performance, including resolution, refresh rate, power consumption, brightness stability, and manufacturing cost.

This article explains how these four technologies work, compares their strengths and weaknesses, and discusses where each is best suited.



1. The Role of the TFT Backplane

A simplified display structure consists of:

• Backlight (for LCD)
• TFT Backplane
• Liquid Crystal Layer (LCD only)
• Color Filter
• Polarizers

For OLED displays, the backlight is eliminated, but the TFT backplane remains essential because each OLED pixel must be individually driven.

The TFT backplane acts like millions of tiny switches that control each pixel. Different TFT technologies determine how efficiently and accurately those pixels can be driven.



2. Evolution of TFT Technologies

The development of TFT technologies generally follows this path:

a-Si

├────────► IGZO

└────────► LTPS

│

▼

LTPO

Each new generation improves performance while introducing additional manufacturing complexity and cost.



3. a-Si (Amorphous Silicon)

Overview

Amorphous Silicon (a-Si) is the oldest and most widely adopted TFT technology. It has been the industry standard for LCD manufacturing for more than two decades.

Unlike crystalline silicon, amorphous silicon has a disordered atomic structure. As electrons move through the material, they encounter many obstacles, resulting in relatively poor electrical performance.

Typical electron mobility:

0.5–1 cm²/V·s



Advantages

Lowest Manufacturing Cost

a-Si benefits from mature manufacturing processes, high production yields, and relatively inexpensive equipment.

It remains the preferred choice for:

• Large LCD televisions
• Office monitors
• Entry-level notebooks
• Budget smartphones



Excellent Manufacturing Yield

Because the fabrication process is simple and well established, manufacturers can achieve consistently high yields, making a-Si highly cost-effective.



Ideal for Large Panels

Large displays such as:

• 65-inch TVs
• 75-inch TVs
• 85-inch TVs
• 98-inch TVs

are still predominantly manufactured using a-Si TFT technology.



Limitations

a) Low Electron Mobility

The relatively slow movement of electrons limits charging speed for each pixel.

As a result, a-Si struggles with:

• Ultra-high resolutions
• Very high pixel densities
• Extremely high refresh rates

For example:

• 4K at 60 Hz is well within its capability.
• 4K at 240 Hz becomes extremely difficult.



b) Higher Power Consumption

Because leakage current is relatively high, pixels require more frequent refreshing, increasing overall power consumption.



c) Not Suitable for OLED

OLED pixels require stable current control rather than simple switching. The electrical characteristics of a-Si make it unsuitable for driving OLED panels.



IGZO (Indium Gallium Zinc Oxide)

Overview

IGZO is an oxide semiconductor technology that offers significantly higher electron mobility than a-Si while maintaining extremely low leakage current.

Typical electron mobility:

10–50 cm²/V·s

This represents roughly a 10–50× improvement over a-Si.



Advantages

Excellent Power Efficiency

One of IGZO’s greatest strengths is its extremely low leakage current.

Pixels can maintain their electrical charge for much longer, reducing the need for constant refreshing.

This makes IGZO particularly efficient when displaying static content such as:

• Documents
• Web pages
• PDFs
• Spreadsheets



Higher Resolution Support

The improved mobility allows significantly higher pixel density, making IGZO well suited for Retina-class displays.



High Refresh Rate Capability

IGZO comfortably supports:

• 120 Hz
• 144 Hz
• 165 Hz

making it an excellent choice for premium LCD products.



Perfect Match for Mini LED LCD

Mini LED displays rely on thousands of local dimming zones that require fast and precise control.

IGZO provides the speed and efficiency needed for these premium displays.



Limitations

• Higher Manufacturing Cost

Compared to a-Si, IGZO requires more advanced materials and manufacturing equipment.



• Lower Mobility than LTPS

Although much faster than a-Si, IGZO still cannot match the extremely high electron mobility of LTPS.

For applications demanding maximum pixel density and the fastest switching speeds, LTPS remains superior.



LTPS (Low Temperature Polycrystalline Silicon)

Overview

LTPS is created by transforming amorphous silicon into polycrystalline silicon using laser annealing.

The resulting crystal structure allows electrons to move much more freely.

Typical electron mobility:

100–200 cm²/V·s

This is over 100 times faster than a-Si.



Advantages

Extremely High Pixel Density

LTPS can support pixel densities exceeding:

• 500 PPI
• 600 PPI
• 700 PPI

making it ideal for smartphones and other compact displays.



Excellent High Refresh Rate Performance

LTPS easily supports:

• 120 Hz
• 165 Hz
• 240 Hz

and even higher refresh rates.



Smaller TFTs

Because LTPS transistors are more efficient, they occupy less space.

This allows:

• Narrower bezels
• Higher aperture ratio
• Improved display efficiency



Ideal for OLED

OLED displays require precise analog current control for every pixel.

LTPS provides the high drive capability necessary for excellent OLED image quality.

Today, most smartphone OLED displays use LTPS technology.



Limitations

Higher Leakage Current

The same characteristics that enable high-speed operation also increase leakage current.

Static images therefore consume more power compared with IGZO.



More Expensive Manufacturing

Laser annealing equipment is expensive, and process control is considerably more complex than for a-Si or IGZO.



LTPO (Low Temperature Polycrystalline Oxide)

Overview

LTPO is not a completely new semiconductor material.

Instead, it combines the strengths of both LTPS and IGZO within the same TFT backplane.

A simplified view is:

• LTPS provides high-speed pixel driving.
• IGZO minimizes leakage current and maintains pixel charge.

Together, they deliver both high performance and excellent energy efficiency.



The Biggest Advantage of LTPO: Variable Refresh Rate

The defining feature of LTPO is its ability to dynamically adjust refresh rate over a very wide range.

For example:

• 1 Hz while displaying a static image
• 10 Hz during Always-On Display mode
• 30–60 Hz for reading
• 90–120 Hz while scrolling
• 120–165 Hz during gaming

This dramatically reduces power consumption without sacrificing responsiveness.



Always-On Display

LTPO enables displays to refresh at just 1 Hz, allowing the screen to remain active while consuming minimal power.

This capability has become a defining feature of flagship smartphones and smartwatches.



Technology Comparison

Feature	a-Si	IGZO	LTPS	LTPO
Electron Mobility	Low	Medium	Very High	Very High
Power Consumption	Medium	Very Low	Medium	Very Low
Leakage Current	High	Extremely Low	High	Low
High PPI Support	Fair	Good	Excellent	Excellent
High Refresh Rate	Fair	Good	Excellent	Excellent
Variable Refresh Rate	Limited	Limited	Limited	Outstanding
OLED Compatibility	Poor	Limited	Excellent	Excellent
Manufacturing Cost	Lowest	Medium	High	Highest
Manufacturing Complexity	Low	Medium	High	Very High



Typical Applications

a-Si

• LCD televisions
• Office monitors
• Budget laptops
• Industrial displays

IGZO

• Premium LCD monitors
• Mini LED displays
• Tablets
• Professional monitors

LTPS

• Smartphone OLED displays
• High-resolution mobile LCDs
• AR/VR displays

LTPO

• Flagship smartphones
• Smartwatches
• Premium OLED mobile devices



Which Technology Is Best?

There is no single “best” TFT technology. Each one is optimized for different priorities.

• a-Si remains the most economical solution for large displays where cost is the primary concern.
• IGZO provides an excellent balance of power efficiency, image quality, and performance, making it ideal for premium LCD products.
• LTPS delivers the highest driving capability and pixel density, making it the preferred choice for smartphone OLED displays.
• LTPO combines the speed of LTPS with the efficiency of IGZO, enabling adaptive refresh rates and significantly improved battery life. It has become the technology of choice for today’s flagship mobile devices.



Final Thoughts

Although consumers often focus on display resolution or brightness, the TFT backplane technology is one of the most important factors determining the overall user experience.

From the affordability of a-Si, to the efficiency of IGZO, the high performance of LTPS, and the adaptive intelligence of LTPO, each technology represents a different balance between cost, power consumption, and display capability.

Understanding these technologies helps explain why different products—from budget monitors to premium smartphones—are built the way they are, and why manufacturers continue to invest in more advanced TFT backplane technologies as display performance continues to evolve.

If you have questions or would like to explore your next design, please contact our engineering.

The modern automotive cockpit is undergoing a massive design shift. Gone are the days of rigid, flat, rectangular screens slapped onto the center console. Today, tiers and OEMs are treating the dashboard as a continuous, flowing canvas.

Designing a Curved Touch Screen introduces unique optical, mechanical, and manufacturing complexities that don’t exist with flat glass. Understanding how these screens are built—and where the technology is heading—is crucial for display engineers, product managers, and industrial designers alike.

Let’s break down the four distinct generations of curved touch screen technology, evaluating the mechanical engineering, bonding constraints, and material science behind each.





The 4 Generations of Curved Touch Screen Technology

1st Gen: The “Aesthetic” Curve (IML + Flat Glass Touch)



In the early days of curved automotive interiors, the display technology wasn’t curved. The active display area and button area remained completely flat.

Instead, the curvature was restricted entirely to the border/mid area using In-Mold Labeling (IML) or injection-molded plastic trim. A flat glass touch panel was embedded inside a curved housing. While this achieved a fluid look on the dashboard, it lacked seamless integration; the distinct boundary between the flat screen and the curved plastic frame remained highly visible.



2nd Gen: The Multi-Screen Unity (Cold Bending Lens + Glass Touch)

To achieve a premium, single piece look without a massive price tag, the industry developed Cold Bending. This is currently the dominant technology for large, integrated dual or triple-screen setups (the “pillar-to-pillar” display).

• The Architecture: The underlying LCD display panels and touch sensors are flat, but they are covered by a single, large sheet of protective glass that is curved in the middle or at the borders.
• The Process: Glass is chemically strengthened while perfectly flat. During final assembly, it is mechanically forced into a curved bezel frame at room temperature.
• Engineering Advantage: Because the glass isn’t heated, it retains pristine optical quality, suffers no thermal distortion, and keeps manufacturing costs relatively low. However, it is strictly limited to shallow, gentle 2D cylindrical bends because the glass remains under constant internal mechanical stress.



3rd Gen: Functional Geometry (Hot Bending Lens + Glass/Film Touch)

When a design demands aggressive curves,  or a complex 3D shape—cold bending fails, which is Hot Bending.

• The Architecture: The primary display area remains flat (to accommodate rigid LCDs), but the button/control area transitions into a steep curve, forming a waterfall screen or an L-shaped console.
• The Process: Flat glass is placed over a precise graphite mold and heated to its softening point (around 600°C–700°C). Gravity or pressure shapes the glass to the mold. Crucially, chemical strengthening must happen after this thermal process, otherwise, the heat destroys the tempering layer.
• The Challenge: Because the touch area now wraps around a tight radius, traditional rigid Glass-on-Glass (GG) touch sensors can crack. Engineers must transition to Film-based touch sensors (Metal Mesh or AgNW on PET) that can flex to conform to the inner curvature of the hot-bent lens.



4th Gen: Ultimate Freedom (True Flexible Touch & Display)

The cutting edge of cockpit design abandons flat internal components altogether. In the 4th generation, both the display area and the touch sensor are natively curved.

• The Architecture: The screen seamlessly flows along the contours of the dashboard, fitting curved instrument clusters or wrapping around the driver in a semi-enclosed cockpit.
• The Technology: This relies on Flexible OLED substrates paired with CPI (Colorless Polyimide) or ultra-thin flexible touch sensors.
• Performance Metrics: These assemblies utilize sensors engineered to withstand tight bending radius,  and endure over 200,000 bending cycles, offering massive design freedom while maintaining high reliability in harsh environments (operating from -40C up to 95C).



Key Engineering Challenges in Curved Display Design

Whether implementing a Gen 2 cold-bent system or a Gen 3 hot-bent module, front-end design requires balancing several physical trade-offs:

1. Bonding Methodology: OCA vs. OCR

Connecting a curved cover lens to the display panel is a major yield-rate variable.

• OCA (Optically Clear Adhesive) Tape: Standard flat OCA films tend to struggle on curved surfaces. The internal rebound stress of the bent glass causes the tape to pull away at the edges, leading to delamination and bubbles over time.
• OCR/LOCA (Optically Clear Resin / Liquid Glue): Liquid bonding is highly preferred for curved geometries. The liquid flows naturally to fill the uneven tolerances and gaps created by the curve. However, it requires highly specialized fixture tooling to prevent overflow and ensure a completely uniform bond-line thickness across the bend.

2. Optical Distortion and Reflection Management

Curved surfaces inherently behave like lenses. As the radius of curvature sharpens, light traveling from the flat display through the curved glass bends, causing visual distortion, ghosting, or color shifts at wide viewing angles.

Furthermore, while flat glass reflects ambient light in one predictable direction, a curved surface captures and concentrates glare from multiple angles. Specifying high-performance Anti-Reflective (AR) and Anti-Glare (AG) coatings is mandatory. However, depositing these coatings uniformly across a steep 3D curved surface without pooling or thinning at the apex is a major manufacturing hurdle.

3. Dimensional Tolerance Stack-up

Thermal bending introduces minor batch-to-batch variations in the exact radius of curvature. If the inner radius of your cover glass doesn’t perfectly match the profile of the display or mounting bracket, it creates uneven pressure points. In production, this can cause localized pooling of liquid glue, leading to visual artifacts on the display (the Mura effect) or, worse, causing the display panel to crack under mechanical stress.



Conclusion

The evolution of the curved touch screen is a journey of removing mechanical constraints from user experience design. While Gen 2 cold bending offers an excellent middle ground for cost-effective, wide screen setups today, the future belongs to Gen 4 flexible architectures.

As material science advances in flexible substrates and high-reliability liquid optical bonding, the dashboard will transition from a place where displays are mounted, to a surface that is entirely a display.

If you have questions or would like to explore your next design, please contact our engineering.

SPI Command Mode LCDs: The Day I Realized Most “SPI Displays” Aren’t Really Streaming Video

When I first started working with embedded displays, I always believed I was using a “pure SPI display.” The MCU continuously sent data through SPI, the screen updated in real time, and from the outside it looked exactly like video streaming. But after digging deeper into how LCD controllers actually work, I realized something important:

Most so-called “SPI displays” are not true streaming displays at all. They are actually Command Mode Displays with internal memory.

And honestly, that realization completely changed how I think about embedded display systems.



What Is an SPI Command Mode Display?

An SPI Command Mode LCD is a display where the MCU sends commands and image data through SPI, while the display controller itself handles the actual screen refreshing.

The key reason is simple:

The display driver IC contains internal frame memory, usually called GRAM (Graphics RAM). Once image data is written into GRAM, the display controller continuously refreshes the panel automatically. The MCU only updates the content when something changes.

In other words:

• MCU updates the image
• The display handles the refreshing

The MCU does not continuously “feed” the display.



Why These Displays Are So Popular

SPI command displays are extremely common in embedded systems because they simplify both hardware and software design. They offer several major advantages:

Lower Pin Count

SPI interfaces typically require only a few signals:

• MOSI
• MISO
• SCK
• CS
• DC

Compared to RGB interfaces, routing is much simpler and connectors can be much smaller.

Lower EMI

SPI uses serial communication with relatively low bandwidth compared to parallel video interfaces. That usually means:

• Lower EMI
• Easier EMC design
• Better suitability for industrial and medical products

Partial Refresh Support

This is one of the biggest advantages. Instead of refreshing the entire screen, the MCU can update only the region that changes.

For example:

• Updating the whole screen may require over 100 KB of data
• Updating only several digits may require just a few KB

That significantly reduces bandwidth and power consumption.



Real-World Embedded Products

Many modern embedded display modules are built around command-mode display architectures with internal GRAM.

For example, our P Series SPI display modules use SPI command interfaces together with onboard display controllers, making them suitable for industrial HMIs, medical devices, handheld devices, and other embedded systems where low EMI and partial refresh are important.

Some products simplify the architecture even further. Our AGN/AGU UART display modules allow the host MCU to communicate through high-level UART commands, while the display module internally handles rendering, framebuffer management, and screen refreshing. This significantly reduces MCU workload and simplifies embedded software development.

We also provide ACN series MCU-interface display modules, which are designed for embedded systems requiring direct MCU communication together with command-based display control architectures.

In many cases, developers are not directly driving LCD pixels at all. They are simply updating display content while the display controller manages the actual refresh process internally.





Why SPI Feels Like Video Streaming

This misunderstanding is actually very common. I had it myself for years. And honestly, it makes perfect sense.



1. SPI Looks Continuous

SPI can transfer data very quickly.

In many projects, we continuously send image data through SPI, sometimes even refreshing the full screen repeatedly.

Visually, it feels exactly like streaming video.



2. The Name “SPI Display” Is Misleading

People constantly say things like:

• SPI LCD
• SPI display
• SPI screen

The focus is always on the communication interface, not the display architecture itself. So naturally, many engineers unconsciously assume: SPI = directly driving pixels in real time; But actually: SPI is only the transport method.

The display mode is a completely separate concept.



3. Driver Libraries Hide the Commands

In application code, we often write something simple like:

LCD_DrawImage(…);

But underneath that function, the driver is actually:

• Setting display windows
• Configuring GRAM addresses
• Sending commands
• Starting memory writes

All of this is heavily abstracted away.

So over time, it feels like:

“I’m just continuously sending image data.”

Even though the display is actually operating in command mode the entire time.



4. We Are Updating Memory, Not Driving Pixels

This was the biggest mental shift for me.

Most SPI displays internally store image data inside GRAM.

What we are really doing is:

Writing image data into the display’s internal framebuffer. The display controller then takes care of refreshing the panel itself. That is fundamentally different from true video streaming.

And because this process is mostly invisible to developers:

• We never see the refresh timing
• We do not manage line scanning
• The image remains even after SPI stops

It creates the illusion that we are directly driving the panel. But we are not. We are simply updating what the display should show.





Command Mode vs Video Mode

The core difference is actually very simple.

Command Mode	Video Mode
Internal GRAM exists	Little or no framebuffer
Display refreshes automatically	Continuous pixel stream required
MCU updates when needed	MCU continuously outputs frames
Partial refresh supported	Usually full-frame streaming
Image remains after communication stops	Display stops without input

Typical command-mode interfaces:

• SPI
• MCU/8080 interfaces

Typical video-mode interfaces:

• RGB Parallel
• LVDS
• MIPI DSI Video Mode



The Most Important Realization

Eventually I realized something very important:

I was never truly driving pixels in real time.
I was only updating what the display should show.

The display itself was handling the refreshing all along.

And once I understood that:

• Bandwidth calculations made more sense
• Partial refresh became intuitive
• EMI behavior became easier to understand
• MCU optimization became much clearer

Many embedded display design decisions suddenly stopped feeling mysterious.



Final Thoughts

Looking back, this misunderstanding is incredibly common because several factors combine together:

• SPI visually resembles streaming
• Full-screen refreshes imitate video behavior
• Driver libraries hide the commands
• Internal GRAM is invisible to developers
• “SPI display” terminology is misleading

So, it becomes very natural to assume:

“SPI displays are continuously streamed displays.” But in reality, most of them are better understood as: A display terminal with built-in memory.

And honestly, once you realize that difference, you start thinking about embedded displays in a completely different way.



If you have questions or would like to explore your next design, please contact our engineering.

Designers often envision color displays that can be created in any shape or size to perfectly match their product aesthetics. In reality, however, display designs are typically constrained by standard TFT or OLED panel sizes.

Customizing a TFT or OLED display can be prohibitively expensive due to high non-recurring engineering (NRE) costs. For example, developing a custom display at Gen 5 TFT production line can require an investment of approximately $300,000 to $400,000. In addition, development cycles are long and generally only feasible for high-volume projects.

To address these challenges, the engineering team at Orient Display has explored innovative approaches to enable more flexible and visually appealing display designs. These concepts have proven highly useful for designers seeking customization without the cost of fully custom panels. Most of these solutions are based on dead-front (all-black) display designs, which offer both aesthetic and functional advantages.



What is a Dead-Front Display?

A dead-front display is a user interface panel that appears completely uniform, such as black, matte black, white, silver, mirror-like, or even wood-textured. When turned off. In this state, all icons, text, and graphics are fully hidden, creating a seamless and minimalist surface.

When the display is illuminated by a backlight, the hidden elements become visible. This creates a clean, high-end, and modern visual effect, making dead-front displays especially popular in applications such as automotive dashboards, smart home appliances, and control panels.

From left to right: Black Dead Front Display, White Silver Dead Front Display, Mirror Dead Front Display



Wood Texture Dead Front Display



If in-house visual assets are limited, the Google Nest design team provides excellent examples of well-integrated display aesthetics, as shown below.



We will further explore black dead-front display concepts in the following design approaches.

Design 1:  Limited Colors With Fixed-Position Color Displays

For products that require simplicity, clarity, and cost efficiency, this approach delivers elegant results.

By using screen printing to define up to three colors in fixed positions, designers can create clean, intuitive interfaces with strong visual contrast. When the display is off, the surface remains perfectly uniform; when illuminated, only the intended elements appear—crisp and refined.

Why it works:

• Cost-effective solution for mass production
• High reliability and stable color performance
• Ideal for appliances, industrial controls, and minimalistic UI designs



Design 2: Unlimited or Gradient Colors with Fixed-Position Color Displays

When your product demands richer visuals or a more premium feel, this approach removes the limitations of traditional color printing.

Instead of relying on screen printing, color films laminated onto the polarizer enable vibrant, multi-color or gradient effects with superior consistency. This allows designers to create visually striking interfaces that stand out in competitive markets.

To ensure optimal visual quality, we recommend maintaining at least 2 mm spacing between color segments to prevent crosstalk.

Why it stands out:

• Enables unlimited or gradient color designs
• Delivers a more premium, high-end appearance
• Ideal for smart home devices, consumer electronics, and branded UI experiences





Design 3: Hybrid Fixed-Position Color Displays with TFT or AMOLED

For the most advanced applications, hybrid designs combine the best of both worlds—static elegance and dynamic intelligence.

By integrating fixed-position color elements with TFT or AMOLED displays, designers can create interfaces that are both visually distinctive and functionally powerful.

Static icons, branding elements, or color zones remain crisp and consistent, while dynamic display areas provide rich content, animation, and interactivity.

What this unlocks:

• Premium, futuristic product designs
• Seamless integration of static and dynamic UI elements
• Maximum design freedom without full custom panel costs

Structure of the Hybrid Passive LCD and Active TFT/AMOLED Display









From Concept to Reality

Great product design is no longer limited by standard display formats. With the right approach, you can achieve custom-looking designs without custom-level cost and risk.

At Orient Display, our engineering team works closely with customers to turn design concepts into manufacturable, high-performance display solutions.

Let’s build something distinctive together.

If you have questions or would like to explore your next design, please contact our engineering.
